Product Summary
The MC33341DR2 is a monolithic regulation control circuit that is specifically designed to close the voltage and current feedback loops in power supply and battery charger applications.
Parametrics
Absolute maximum ratings: (1)power supply voltage (pin 7): 16 V; (2)voltage: -1.0 to VCC; (3)drive output spurce current: 50 mA; (4)thermal resistance, junction-to-air: P suffix, DIP plastic package, case 626: 100 ℃/W, D suffix, SO-8 plastic package, case 751: 178 ℃/W; (5)operating junction temperature: -25 to +150 ℃; (6)storage temperature: -55 to +150 ℃.
Features
Features: (1)Differential Amplifier for High-Side Source and Load Current Sensing; (2)Inverting Amplifier for Source Return Low-Side Current Sensing; (3)Non-Inverting Input Path for Load Low-Side Current Sensing; (4)Fixed or Adjustable Current Threshold in All Current Sensing Modes; (5)Positive Voltage Sensing in All Current Sensing Modes; (6)Fixed Voltage Threshold in All Current Sensing Modes; (7)Adjustable Voltage Threshold in All Low-Side Current Sensing Modes; (8)Output Driver Directly Interfaces with Economical Optoisolators; (9)Operating Voltage Range of 2.3 V to 16 V; (10)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 MC33341DR2 |
ON Semiconductor |
Battery Management 2.3-15V Power Supply |
Data Sheet |
Negotiable |
|
||||
|
MC33341DR2G |
ON Semiconductor |
Battery Management 2.3-15V Power Supply Charger w/Regulation |
Data Sheet |
Negotiable |
|
||||
