Product Summary
The AD6481js6449-48bb is a Dual Precision, Low Power BiFET Op Amp. The AD6481js6449-48bb offers both low bias current (10pA max, warmed up) and low quiescent current (400mA max) and is fabricated with ion-implanted FET and laser wafer trimming technologies. Input bias current is guaranteed over the AD6481js6449-48bb’s entire common-mode voltage range.
Parametrics
AD6481js6449-48bb absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Internal Power Dissipation: 500 mW; (3)Input Voltage: ±18 V; (4)Output Short Circuit Duration: Indefinite; (5)Differential Input Voltage: +VS and –VS; (6)Storage Temperature Range (Q, H): –65 to +150℃; (7)Storage Temperature Range (N, R): –65 to +125℃; (8)Operating Temperature Range; (9)AD648J/K: 0℃ to +70℃; (10)AD648A/B/C: -40°C to +85℃; (11)AD648S/TL: –55 to +125℃; (12)Lead Temperature Range (Soldering 60 sec): +300℃.
Features
AD6481js6449-48bb features: (1)400 mA max Quiescent Current; (2)10 pA max Bias Current, Warmed Up (AD648C); (3)300 mV max Offset Voltage (AD648C); (4)3 mV/℃ max Drift (AD648C); (5)2 mV p-p Noise, 0.1 Hz to 10 Hz; (6)1.8 V/μs Slew Rate; (7)1 MHz Unity Gain Bandwidth; (8)Available in Plastic Mini-DIP, Cerdip, Plastic SOIC and Hermetic Metal Can Packages; (9)MIL-STD-883B Parts Available; (10)Surface Mount (SOIC) Package Available in Tape and Reel in Accordance with EIA-481A Standard; (11)Single Version: AD548.
Diagrams
 |
